Specs
POWER
627cc Commercial-Grade, V-Twin OHV-Technology, EFI Vanguard 4-stroke Gas Engine. Superior balance, low vibration, reduced emissions, improved valve life, improved fuel economy and higher HP/Weight
TORQUE
34.5 ft-lbs.
SPEED
35 mph**
FUEL CONSUMPTION
Up to 18 mpg**
RANGE
Up to 100 miles**
STARTING
12V keyed ignition
BATTERY
12V / 315 cca utility class
SPARK PLUG
NGK C7HSA
FUEL CAPACITY
5.0 gal
ALTERNATOR
16 amp
TRANSMISSION
CVT automatic
TRANSAXLE
Gear drive Schafer/DANA oil-filled transaxle
DIFFERENTIAL
Cable Actuated Rear-Locking
DRIVE
Switch engaged on demand, 4 wheel drive
FRONT SUSPENSION
Double A-arms, adjustable coil over shock with up to 8" travel
REAR SUSPENSION
Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coil over shock with up to 8" of travel
BRAKE SYSTEM
4 wheel disc, hydraulic brake / hand-operated parking brake
TIRES
25 x 8 - 12 (front) 25 x 10 - 12 (rear)
DIMENSIONS
95” L x 58” W x 76” H (110” L with poly bed)**
WHEEL BASE
73”
TURNING RADIUS
9’ inside radius
CURB WEIGHT
1,270 lbs.
BED MATERIAL
“Poly Bed” with stake pockets
BED DIMENSIONS
35.25” L x 41.5” W x 11” D
GROUND CLEARANCE
11"
*BED CAPACITY
Poly - 9 cu.ft. / 500 lbs.
TOWING CAPACITY
1,500 lbs.
TOTAL CAPACITY
900 lbs. / HD 1,100 lbs.
WARRANTY
3 year engine / All other 1 year limited
ADDITIONAL FEATURES
DOT certified 3pt lap/shoulder belts for driver and passenger, twin 12V auxiliary outlets for accessories, 12V/18W LED headlights, polyurethane powder paint, 2” front and rear receiver hitch, poly dump bed standard, bench seating, welded steel frame. Complete weather-sealed wiring connections. Wide selection of additional accessories available along with three bed options. Fuel gauge located under seat. In-dash, hour/volt meter standard. EPS Standard.
