Specs
POWER
570cc Commercial-Grade, V-Twin OHV-Technology, Carburated Vanguard 4-stroke Gas Engine. Superior balance, low vibration, lower emissions, improved valve life, better fuel economy and higher HP/Weight
TORQUE
28.7Ft-Lbs
SPEED
Up to 24 mph**
FUEL CONSUMPTION
Up to 18 mpg**
RANGE
Up to 100 miles**
STARTING
12V keyed ignition
BATTERY
12V / 315 cca utility class
SPARK PLUG
NGK C7HSA
FUEL CAPACITY
5.0 gal
ALTERNATOR
20 amp
TRANSMISSION
CVT automatic
TRANSAXLE
Gear drive Schafer/DANA oil-filled transaxle
DIFFERENTIAL
Cable Actuated Rear-Locking
DRIVE
2 wheel drive
FRONT SUSPENSION
Double A-arms, adjustable coil over shock with up to 8" travel
REAR SUSPENSION
Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coil over shock with up to 8" of travel
BRAKE SYSTEM
4 wheel disc, hydraulic brake / hand-operated parking brake
TIRES
25 x 8 - 12 (front) 25 x 10 - 12 (rear)
DIMENSIONS
110” L x 51” W x 78” H (with poly bed and poly roof)**
WHEEL BASE
73”
TURNING RADIUS
9’ inside radius
CURB WEIGHT
1,200 lbs.
BED MATERIAL
“Poly Bed” with stake pockets
BED DIMENSIONS
35.25” L x 41.5” W x 11” D
GROUND CLEARANCE
11"
*BED CAPACITY
Poly - 9 cu.ft. / 500 lbs.
TOWING CAPACITY
1,500 lbs.
TOTAL CAPACITY
900 lbs. / HD 1,100 lbs.
WARRANTY
3-year engine / All other 1-year limited
