Specs
POWER / MOTOR
24 hp (18.0 kW) with 71.5 ft lbs torque rating – AC Motor powered by a 48V Lithium-Ion battery powerplant (5.0kW or 8.0kW)
SPEED
24MPH
RANGE
Up to 50 miles ( 160Ah battery)*
STARTING
Keyed on/off
BATTERY
Extended Range 48V 160Ah Lithium Iron Phosphate
TRANSMISSION
Direct drive
ALTERNATOR
25 amp
TRANSAXLE
Model 24 Schafer
DIFFERENTIAL
Cable Activated Locking
DRIVE
4wd (Switch engaged on demand, 4 wheel drive)
FRONT SUSPENSION
Double A-arms, adjustable coilover shock with up to 8" travel
REAR SUSPENSION
Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coilover shock with up to 8" of travel
BRAKE SYSTEM
4 wheel disk, hydraulic brake
TIRES
25” Standard Max-Terrain HD DOT / Radial 8 Ply Tires on 12” Steel Wheels
DIMENSIONS
145” L x 58” W x 76” H
WHEEL BASE
105"
TURNING RADIUS
14' inside radius
GVWR
2,560 lbs.
CURB WEIGHT
1,560 lbs.
BED MATERIAL
XL Convertible Steel Bed / Flat Bed - with electric dump
BED DIMENSIONS
35.25” L x 41.5” W x 11” D
GROUND CLEARANCE
11"
*BED CAPACITY
Steel - 21 cu.ft. / HD-LROSS - 1000 lbs.
TOWING CAPACITY
1500 lbs.
TOTAL CAPACITY
900 lbs.
WARRANTY
1-year motor / all other 1-year limited, 5-year prorated Lithium Iron Phosphate battery
ADDITIONAL FEATURES
On-board charger, 3pt lap/ shoulder belts for driver & passenger, 12V/18W LED headlights, 2” rear and front receiver hitch, welded steel frame, Single 12V auxiliary outlet for accessories, polyurethane powder paint. Complete weather-sealed wiring connections. Wide selection of additional accessories available along with three bed options. In-dash, hour meter standard. LED true state of charge meter for the 48 volt system is standard. Low charge audible warning. Battery shut down switch. Electric accelerator pedal.
HILL CLIMBING CAPABILITIES
Your AMP is capable of climbing continuous inclines up to 25 degrees. Depending on the passenger(s) and cargo weight, expect top speed between 5-10 MPH.
VEHICLE PACKAGES
Standard // Powersteering // Sport
