- Engine Brand Cub Cadet®
- Engine Model Number 690-WUC
- Engine Displacement 420cc
- Fuel Tank Capacity 5 quarts US / 4.7 L
- Engine Start Recoil and Push-Button Electric
- Governor Mechanical
- Fuel Delivery Carburetor
- Number of Forward Speeds 6
- Number of Reverse Speeds 2
- Drive Type Friction Disc
- Drive System All-wheel Drive
- Handle Grip(s) Soft-Touch heated Grips
- Chute Rotation Control Remote Overhead Crank
- Chute Pitch Control Remote Single-Lever
- Chute Rotation 200°
- Single-Hand Operation Standard
- Steering Control Trigger-Controlled Power Steering
Power and Performance
- Clearing Width 30"
- Intake Height 23"
- Auger Gear Box Heavy-duty cast aluminum
- Number of Stages Three
- Auger Diameter 12"
- Impeller Diameter 12"
- Accelerator Diameter 12"
- Tire Size 16" x 6.5"
- Tread Xtrac®
- Headlight(s) Dual LED and LED Light Bar
- Shave Plate Heavy Duty Steel
- Skid Shoes Reversible Poly
- Drift Cutters No
- Auger Material Serrated Steel
- Chute Material Steel
- Model Number 31AH5EVW710
- Auger Gearbox Warranty 5-year limited
- Warranty 3-year limited residential
- Commercial Warranty 1-year limited
- Chute Warranty 3-year limited
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
- Snow Removal †Results may vary depending on weather and snow conditions
- Xtrac® Tires **Xtrac® is a registered trademark of the Carlstar Group, LLC
