Specs
POWER
AC motor, powered by a 48V DC Lithium Iron Phosphate Battery up to 8K Watts with 600 amp controller
SEATING
2 Person
SPEED
24MPH
RANGE
Up to 50 miles ( 16Ah battery)*
STARTING
Keyed on/off
BATTERY
48V 160Ah Lithium Iron Phosphate
ALTERNATOR
Converter / 30 amps
TRANSMISSION
Direct drive
TRANSAXLE
Model 24 Schafer
DIFFERENTIAL
Cable Activated Locking
DRIVE
4wd (Switch engaged on demand, 4 wheel drive)
FRONT SUSPENSION
Double A-arms, adjustable coilover shock with up to 8" travel
REAR SUSPENSION
Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coilover shock with up to 8" of travel
BRAKE SYSTEM
4 wheel disk, hydraulic brake
TIRES
25” Standard Gladiator HD DOT / Radial Pro 8 Ply Tires on 12” Steel Wheels
DIMENSIONS
127” L x 59” W x 76” H
WHEEL BASE
105”
TURNING RADIUS
14’ inside radius
CURB WEIGHT
1,560 lbs.
BED MATERIAL
XL Convertible Steel Bed / Flat Bed - with electric dump
BED DIMENSIONS
14.25"h x 50.25" w x 70" L (inside bed dimensions)
GROUND CLEARANCE
11"
BED CAPACITY
Steel - 21 cu.ft. / HD-L-ROSS - 1000 lbs.
TOWING CAPACITY
1,500 lbs.
TOTAL CAPACITY
HD-L-ROSS - 1,000 lbs.
WARRANTY
1-year motor / all other 1-year limited, 5-year prorated Lithium Iron Phosphate battery
ADDITIONAL FEATURES
On-board charger, 3pt lap/ shoulder belts for driver & passenger, 12V/18W LED headlights, 2” rear and front receiver hitch, welded steel frame, Single 12V auxiliary outlet for accessories, polyurethane powder paint. Complete weather-sealed wiring connections. Wide selection of additional accessories available along with three bed options. In-dash, hour meter standard. LED true state of charge meter for the 48 volt system is standard. Low charge audible warning. Battery shut down switch. Electric accelerator pedal.
VEHICLE PACKAGES
Trail
